Koj Puas Paub Xaiv Cov HDMI Cable Li Cas?

Thaum siv lub high-txhais playback platform lossis txawm tias 4K high-txhais playback platform, peb tsis tuaj yeem zam qhov xwm txheej ntawm kev xaiv thiab yuav HDMI cable . Lub sijhawm no, qee cov koom tes me yuav nug, yuav ua li cas xaiv HDMI cable los ua tus kws tshaj lij txuas ntxiv?

Kauj ruam 1: Txiav txim siab HDMI interface version

HDMI interface yog qhov sib txawv, bandwidth thiab kev txhawb nqa thev naus laus zis yog qhov sib txawv, thiab HDMI cable kuj tseem muab faib ua 1.3 mus rau 2.0 version hauv khw thiab HDMI interface, thiab rov qab tau tshaj, yog li HDMI cable yuav tsum tau tshaj HDMI interface version. , tsawg kawg ntawm lub xov tooj xaim yuav tsum siab tshaj qhov sib cuam tshuam cov version.

Yog tias cov ntawv xaiv hlau xaim qis dua qhov sib tshuam, HDMI2.0 interface tau nruab nrog HDMI1.4 cable, uas tsis tuaj yeem xa duab 4K @ 60hz thiab vis dis aus, tab sis yog tias koj muab HDMI1.4 interface nrog HDMI2. 0 cable, Tsis muaj teeb meem dab tsi hauv kev siv, tsuas yog siv nyiaj ntau dua, vim tias qhov muaj ntau ntawm HDMI cable yuav yeej kim me ntsis.

Kauj Ruam 2: Saib cov hlau nrog lossis tsis muaj daim ntawv pov thawj

HDMI ntawv pov thawj

Sinplay ntawv pov thawj

Xyuas seb cov khoom ntim puas muaj HDMI lossis Simplay daim ntawv pov thawj . Cov xov hlau zoo yuav muaj ob lub koom haum cov ntawv pov thawj tib lub sijhawm, thiab cov khoom zoo dua yog kev nyab xeeb.

Kauj Ruam 3: Saib ntawm lub xov hlau txuas

Yog hais tias qhov txuas ntawm HDMI cable yog kub-plated txuas, ntxiv rau qhov zoo nkauj dua, raws li cov tswv yim muaj xeb zoo dua, hluav taws xob zoo thiab qhov kub tsis kam, thiab kuj yog yooj yim solder. Yog li ntawd, cov kub-plated pob qij txha zoo dua li cov tsis muaj kub-plated pob qij txha. Cov pob zeb kub-plated sib txuam ntawm cov khw muag khoom yog 24K kub-plated thiab muaj qhov ci ci. Tab sis nws tsis txhais tau tias cov txuas txuas yog kub-plated, thiab tus pin txuas nrog HDMI txuas. Yog li, HDMI cable txuas yog qhov tseem ceeb tshaj plaws.

tus pin

Cov khoom siv ntawm tus pin feem ntau yog tin bronze, uas muaj lub siab elasticity, zoo heev hnav tsis kam thiab corrosion kuj. Feem ntau, tus pin yuav plated nrog npib tsib xee ntawm tin tooj liab, thiab tom qab ntawd nws yooj yim rau phaj kub. Yog li no, tus pin ntawm HDMI cable nrog kev ua haujlwm tau zoo tuaj yeem soj ntsuam peb txheej.

Kauj Ruam 4: Saib rau kev tsim khoom thiab txheej txheem ntawm xaim

Muaj ntau ntau hom ntaub ntawv rau cov tsoos HDMI hlau xaim. Feem ntau, cov tooj liab zoo tshaj yog tooj liab ntshiab, lossis tooj liab ntshiab yog plated nrog nyiaj. Cov ntshiab tooj liab tuaj yeem lav qhov zoo ntawm lub teeb liab kis, txo teeb liab cuam tshuam thiab teeb liab ploj, thiab siv cov hlau thiab hlau. Raws li lub hauv paus loj. Yuav qhia li cas? Yog lawm, nws yog qhov zoo tshaj plaws los paub qhov txawv thiab pom, thiab nws yog qhov tsis yooj yim sua tshaj plaws. Peb tuaj yeem khoov cov hlau kom yog. Tooj liab tooj liab yog mos thiab hloov tau. Txwv tsis pub, nws yuav tsis yog tooj liab hlau. Nws yog ib qho yooj yim tawg tom qab rov qab khoov.

Cov tub ntxhais fiber

Tam sim no muaj kev hloov pauv tshiab hauv cov tub ntxhais ntawm HDMI cable. Kuv ntseeg tias ntau tus neeg tau txais kev pabcuam tau hnov txog HDMI cable nrog optical fiber ua tus tub ntxhais. Optical fiber HDMI cable siv kho qhov muag hluav taws xob raws li cov khoom xa mus. Piv nrog rau lub teeb liab hluav taws xob tshaj tawm ntawm cov tooj liab hlau, lub teeb liab xa hluav taws xob tuaj yeem ua tiav kev nrawm dua, kev xa xov ntev dua thiab ua tiav lub teeb liab kis.

Sij hawm dhau los, ntev dua qhov kev sib kis ntawm cov tooj liab tub ntxhais hluas HDMI cable, lub teeb liab kis tau sai dua, thiab qhov kho qhov muag fiber ntau HDMI cable tawg los ntawm qhov kev txwv no, thiab nws yog qhov yooj yim kom xa cov cim xa mus rau ntau dua 300m, txhawb 4K 60hz , zoo xa tawm 4K video thiab audio signal, thiab yog kub-qib audio thiab video. Tus neeg siv nyiam. Yog lawm, rau kev siv txhua hnub ntawm peb cov neeg siv khoom nruab nrab, tooj liab tub ntxhais tub ntxhais HDMI cable txaus.

Kauj Ruam 5: Tsis txhob xaiv HDMI cable zoo dhau

Nyob rau hauv ib txwm muaj xwm txheej, nws yog qhov tseeb rau tib lub npe ntawm cov hlau. Qhov loj dua ntawm cov xaim xov tooj ntawm HDMI cable, qhov loj dua qhov chaw hla ntawm thaj tsam ntawm tus neeg xyuas pib, thiab qhov siab dua tam sim no tuaj yeem sib kis tau. Qhov kawg kev ua tiav yog kev xa khoom ntawm HDMI cable. Zoo thiab ruaj khov. Txawm li cas los xij, feem ntau muaj ntau lub npe thib peb ntawm cov kab uas sau cov hlau ntawm lub xaim txhawm rau nce lub xov hlau txoj kab, uas ua rau tib neeg saib tuab heev, yog li ua ntej peb yuav tsum xaiv cov xov hlau ntawm lub hom loj.

Txawm tias muaj hom, HDMI cable uas yog nyias dhau heev yog tsis muaj. Cov khoom siv ntawm tus tub ntxhais thiab tuab ntawm cov ntaub thaiv npog txheej txheem txhua tus muaj feem cuam tshuam nrog lub teeb liab zoo. Cov hlau ntau dhau yuav tsum ua kom cov tub ntxhais thiab cov tiv thaiv tsis muaj txheej txheem, yog li yuav tsum them nyiaj ntau dua. Muaj plaub qho xov hlau sib txuas rau HDMI. Qhov loj dua tus naj npawb, thinner qhov kev xa mus deb. Yog li tus nqi yuav siab dua.

Hauv HDMI cable, Tus nqi ntawm AWG (American hlau tawm) tus nqi yog kev ua haujlwm ntawm cov hlau kab hlau, uas yog qhov peb nquag hais. Tus nqi AWG yog inversely proportional rau lub xaim diam. Tus nqi me dua, qhov loj dua ntawm cov xaim hlua, qhov loj dua tam sim no tuaj yeem nqa tau, thiab ntev dua tus naj npawb ntawm cov xov tooj uas txhawb nqa kev sib kis, tab sis tus nqi coj tau ntau dua.

Hauv kev lag luam, HDMI txwv kev xa mus ntev ntawm cov xov hlau sib txawv yuav nyob nruab nrab ntawm cov nqi hauv qab no:

30 AWG txwv kis tau ntev 5-8 meters;

28 AWG txwv kis tau ntev 12-15 meters;

26 AWG txwv kis tau ntev 18-20 meters;

Qhov 24 AWG txwv kis tau ntev yog 20-25 meters.

Txhawm rau muab nws yooj yim, nyob rau hauv tib lub sijhawm ntawm cov hlau ntawm tib lub npe, qhov me dua cov xov tooj hlau qhov kev ntsuas AWG tus nqi siv, qhov zoo dua cov xov hlau kis tau zoo dua. Yog tias koj tseem tsis xaiv qhov zoo, them tus nqi HDMI cable, Kuv thov ua tsaug rau MSL-quab yuam HDMI cable ntawm no.

Cov khoom siv ua yeeb yam e Ultra Ultra HD Hwm HDMI Cable muab kev ua kom zoo, yooj yim, thiab kev sib zog rau kev txuas koj HDMI-ntaus ntawv rau koj HDTV, 4K / Ultra HDTV, Blu-Ray Player, 3D TV, Roku, Boxee, Xbox360, PS3 , Apple TV, Streaming Player, HD Cable Box, PC lossis lwm lub HDMI-enabled ntaus ntawv .Thov koj tuaj yeem ntsib cov suab thiab yees duab zoo los ntawm koj kev ua yeeb yam hauv tsev.

Hwm HDMI Cable Ntawv Pov Thawj ua kom pom tias lub cable ua tau raws cov qauv kev ua haujlwm siab thiab ua tau zoo teeb tsa los ntawm cov tsim ntawm HDMI thev naus laus zis. Lub cable txhawb nqa 4K @ 60hz, muab kev pom tseeb thiab lub suab zoo rau kev pom qhov kawg.

HDMI Hwm Rau Cov Npav Cable lees paub kev sib raug zoo

HDMI 2.0 qhov tshwj xeeb

Kev ua haujlwm ntau bandwidth mus txog 18Gbps

Txhawb 4K @ 60Hz rau kev daws teeb meem txog 4096x2160

Qhov zoo tagnrho rau High Dynamic Range video

Sai npaum li cas tus nqi rau cov duab du

2m / 6 ft. Zoo tagnrho ntev rau lub laptop rau HDTV teeb

Cov khoom siv nrog built-in HDMI lossis txhawb HDMI adapter

Txhawb 4K digital video thiab ntau cov channel digital
